Technical Data:

face to face lenght acc. EN 558-1
version acc. EN 593 : 2004
terms of acceptance acc. EN 12266-1
flanges acc. EN 1092-2
standard - PN10, marine - PN16
leakproofness class - A
working pressure max. PN16
medium temperature - up to: NBR + 70°C; EPDM + 120°C; KFM + 150°C

Design Features:

The version of execute should be always agreed
Max flow rate : - Liquids (water) 4 m/s, - gases (air) 30 m/s.
Executions with : mechanical, electric, pneumatic drive possibility
All parts are protected against corrosion.

Standard execution : PN10, 70°C, NBR, body's holes screwed, without drive, epoxide paint RAL5005 250µm

Certyficat CE : Hygienic attest by PZH

Application:

Sea water, industrial water, potable water, waste water, fuel oil, air, and other neutral media depending on kind of elastomer.

Assembly:

Baterfly valves are both side action.

Assembly for : DN 40-250 any
                            DN 300 - 600 drive from the side - shaft horizontaly

Other executions on request
